Features
| Warranty length | 5 Years |
|---|---|
| Colour | Black |
| Brand | Mark Levinson |
Tech Specs
Analog Line Stage
- Line Input Impedance: Bal (XLR): 20kOhms; Single Ended (RCA): 10kOhms
- Volume Control: Bal; Voltage Mode; Digitally-Controlled Resistor Network
- Gain: 8.5dB Max
- Output Impedance: 55Ohms
- Output Overload: >4.5V RMS
- Freq Response: 20Hz-20kHz, ±0.03dB; <2Hz-210kHz, +0.1/-3dB
- THD: <0.01%, 1kHz; <0.03%, 20kHz; 2V RMS output
- Signal to Noise Ratio: >96dB (20Hz-20kHz, A-weighted); >93dB (20Hz-20kHz, wideband unweighted)
- Input Sensitivity: 53mV RMS at line input for 2.83V RMS at speaker output, max volume
- System Gain: 34.5dB, Line input to speaker output, max volume setting
Phone Stage
- RIAA Freq Response: 20Hz-20kHz, ±0.3dB
- Infrasonic Filter: Selectable; 20Hz, 1st Order (6dB/Octave)
MM Mode
- Input Resistance: 47Ohms
- Input Capacitance: Selectable; 20, 70, 120,170pF
- Gain: 39dB at 1kHz
- THD: <0.01%, 1kHz, 2V RMS output; <0.05%, 20kHz, 2V RMS output
- Signal to Noise Ratio: >90dB (20Hz-20kHz A Weighted, referred to 2V RMS Out), >78dB (20Hz-20kHz, wideband, unweighted, referred to 2V RMS Out)
- Max Input Level: >6.5mV at 1kHz; >19mV at 20kHz
MC Mode
- Input Resistance: Selectable, 37 to 1000 Ohms
- Gain: 69dB at 1kHz
- THD: <0.01%, 1kHz, 2V RMS output; <0.06%, 20kHz, 2V RMS output
- Signal to Noise Ratio: >71dB (20Hz-20kHz A Weighted, referred to 2V RMS Out), >66dB (20Hz-20kHz, wideband, unweighted, referred to 2V RMS Out)
- Max Input Level: >6.5mV at 1kHz; >19mV at 20kHz
DAC Stage
- Output Voltage: 5.7V RMSat Max Volume
- Freq Response: 20Hz-20kHz, +0/-0.2dB (192kHz/24 Bit); 20Hz-20kHz, +0/-0.05dB (44.1kHz/16 bit)
- THD: <0.0025%, 20Hz-20kHz, at 3V RMS Out (192kHz/24bit); <0.003%, 20Hz-20kHz, at 3V RMS Out (44.1kHz/16bit); <0.006%, 90kHz, at 3V RMS Out (192kHz/24bit)
- Signal to Noise Ratio: >100dB (20Hz-20kHz, 192kHz/24 bit, A weighted); >98dB (20Hz-20kHz, 192kHz/24 Bit, wideband, unweighted); >94dB (20Hz-20kHz, 44.1kHz/16 bit, A weighted); >92dB (20Hz-20kHz, 44.1kHz/16 Bit, wideband, unweighted);
- Sample Rates/Bit Depth: PCM: 32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384kHz; up to 32 bits; DSD Native or DoP; single, double, or quad speed (2.8, 5.6, or 11.2MHz)
- Digital Processing: Full MQA decoding; PCM: Seven user-selectable digital filter settings; user selectable up-sampling to 352.8/384kHz; DSD: Four user-selectable digital filter settings.
Headphone Output
- THD: <0.04%, 20Hz and 1kHz, 2V RMS output, 30Ohms Load; <0.10Hz, 2V RMS output, 30Ohms load
- Output Overload: >3.3V RMS, 30 Ohms Load
- Signal to Noise Ratio: >91dB (20Hz-20kHz, A weighted, referred to 2V RMS out), >87dB (20Hz-20kHz, wideband, unweighted, referred to 2V RMS)
- Output Impedance: <2.5 Ohms, 20Hz-20kHz
Amplifier Section
- Freq Response: <2Hz-20kHz, +0/-0.2dB; <2Hz-100kHz, +0/-3dB
- Signal to Noise Ratio: >103dB (20Hz-20kHz, A weighted); >100dB (20Hz-20kHz, wideband, unweighted)
- THD+ Noise: <0.035% at 1kHz, 125W, 8 Ohms; <0.18% at 20kHz, 125W, 8Ohms
- Output Power: 125W RMS per Channel at 8 Ohms, 20Hz to 20kHz
- Output Impedance: <0.098 Ohms, 20Hz-10kHz; <0.11 Ohms at 20kHz
- Damping Factor: >82, 20Hz-10kHz; >72 at 20kHz
General
- Analog input Connectors: 1 pair XLR, 2 pairs RCA, 1 pair MC Phono RCA, 1 pair MM phono RCA
- Digital Audio Connectors: 2 optical Toslink, 1 asynchronous UBS-B, 1 coaxial S/PDIF RCA,
- Output Connectors: 1 pair RCA, 2 pairs loudspeaker outs (high current binding posts with banana sockets; accept spade lugs with ¼”/6.3mm spacing up to 1/8”3mm thick)
- Control Connectors: 1 RS-232 Port (DB9), 1 IR input, 1 programmable 12V DC trigger out, 1 12V DC Trigger In, 1 Ethernet port
- Mains Voltage: 100VAC, 115VAC, or 230VAC
- Power Consumption: Max 500W, Green mode <0.4W, Power Save 7W
Dimensions
- Height: 154mm
- Depth: 507mm
- Width: 438mm
- Weight: 28.1kg
Product Description
Mark Levinson No 5802 Integrated Amplifier is designed for all your digital music sources, it provides a pure and vibrant audio performance and is made with top grade components so it can power every loudspeaker. The 5802 is great for any hifi system and will give you an unforgettable experience.
Why Mark Levinson 5802?
The Mark Levinson No. 5802 is an integrated amplifier that combines a high-grade preamp, a class-A/B power amp and a custom built Precision Link II DAC in one sleek and robust unit. It sits below the bigger 5805 integrated amp as it’s designed only for digital audio but produces a performance that is dynamic and pure, which allows you to feel the very soul of the artist’s performance.
5802 vs. 5805
The No 5802 differs from the No 5805 as it doesn’t have any analogue inputs or a phono stage for connection to a turntable. If you need these inputs then the 5805 is for you but if not, the 5802 will provide everything you need to achieve a great hi fi system.
Precision Link II DAC
To get the most out of your digital music sources, the no 5802 has a built in custom built Precision Link II digital to analogue converter, which delivers audio with pristine detail and with minimal distortion.
Extremely Low Distortion Level
The no 5802 amp uses class-A/B amplification and has a highly reliable power supply (500+ VA toroidal transformer) that is designed to deliver the correct amount of power to any set of loudspeakers and produce an audio performance that is rich, detailed, powerful and distortion free.
Bluetooth AptX
You can connect your wireless devices to the No 5802 amp with the use of Bluetooth AptX, which is a highly reliable and an incredibly good quality version of Bluetooth. Bluetooth AptX allows you to listen to music with the best wireless quality so you can enjoy all the music, podcasts and radio you need from your favorite streaming providers.
High End Headphone Listening
The No 5802 amp has a built in class A analogue stage that powers your headphones so that you can listen to your music privately and at excellent quality.
