Features
| Warranty length | 5 Years |
|---|---|
| Colour | Black |
| Brand | Monitor Audio |
Tech Specs
- System Format: Active sub-woofer amplifier
- Lower Frequency Limit: 25 Hz
- Upper Frequency Limit: Variable 40 – 120 Hz @ 24 dB/Octave
- Amplifier Output: 250 W @ < 1% THD+N
- Drive Unit Complement: 4 - 8 ohms
- Amp Classification: Class D amplifier with Switch mode power supply (SMPSU)
- Cabinet Support: For use when using the dedicated back box
- EQ: Music/ Movie/ Impact
- Phase Control: 0 & 180 degrees
- Auto Sensing: Line Level > 3.5mV
- Input Level Requirements: Standby after approximately 15 minutes if no signal sensed
- Input Impedance: > 20K Ohms
- Mains Input Voltage: AC 110 - 120 V ~ 50/60Hz AC 220 - 240 V ~ 50/60Hz (Factory Region Preset)
- Dimensions (H x W x D): 43.7 x 432 x 263 mm (13/4 x 17 x 103/8)
- Connection: LFE in (Stereo RCA and Balanced)
- 12v Trigger in (3.5 mm mono mini-jack), left and right speaker output
- Trigger Input: 5 - 12v via 3.5 mm mono mini-jack socket
- Power Consumption: Standby: < 0.5 W (ErP approved) Typical Idle: < 10 W - Max Rated: 200 W
- Weight (unpacked): 4 kg (8 lb 12 oz)
Product Description
Monitor Audio IWA-250 Custom Installation Amplifier is the matching amplifier for the IWS-10 in wall subwoofer. It features a streamlined design in a heavy duty 1U rack mount case for dedicated power.
Power for Larger Rooms
The IWA-250 deliver a powerful performance of up to 250 watts into 4 ohms. A single IWA-250 can power single or dual IWS-10's to provide higher levels of power for larger spaces or where required.
Key Features
- Rigid, high quality steel case
- Switch mode power supply
- Class D power amplifier delivering up to 250 watts into 4 ohms (dual IWS-10 drivers)
- High efficiency design resulting in cool running – low thermal output
- DSP controlled with advanced limiters
- <0.5watt standby power consumption (ErP certified)
- DC short circuit protection, over-current and thermal protection
