Features
| Warranty length | 6 Years |
|---|---|
| Brand | ATC Speakers |
Tech Specs
- Output Power: HF 100W into 6Ω,
Mid 200W into 16Ω,
LF 275W x 2 into 8Ω
- Input Sensitivity: 1V
- Input Impedance: 5Hz – 20 kHz ±0.1dB
- Signal to Noise Ratio:Better than 105dB
- Crosstalk: Better than 90dB
- Power Requirements: 100, 115, 230 Volts
(region dependant 50/60Hz factory set)
- Dimensions: 19 Rack Mounting 5U high (222mm / 8.7),
Overall Depth 545mm (21.4),
Front Panel and Handles 75mm (3),
Rear Handles 40mm (1.6),
Amplifier Body 430mm (16.9 )
- Weight: 40kg approx.
Product Description
ATC P4 Mono Power Amplifier is a 4-way mono block design that truly uplifts your sound thanks to ATC's 'Grounded Source Topology' and large power output.
Its sturdy design ensures the model is resilient and durable. The model can only be connected to ATC's active loudspeakers.
Powerful Output
The P4 is brilliantly powerful thanks to its 850W Class AB total output.
Accurate and Clear
The model's fourth order active crossovers complete with phase correction ensures a clear and accurate sound performance.
Attention to Detail
Look out for the P4's opulently soft limiting driver protection and triple fan cooling, for exquisite details that truly enhance the performance of the model.
